Videocast H.265/ H.264 1U 1channel SDI to IP Encoder

About Videocast H.265/ H.264 1U 1channel SDI to IP Encoder

Product Description:

• 1 Channel HD/3G SDI input, 1-channel audio input.
• 1 Channle SDI output,1-channel IP output
• Dual streams output H.265/H.264 format
• Audio: MP3, AAC, G.711 format.

Configuration could be freely adjusted according to the need.

SupportHTTP / RTSP / RTP/ TCP / RTMP / RTMPS / FLV/ UDP / ONVIF / HLS / SRTprotocols.

Redindicator: power. Yellow: Network Green: Streaming status.

• Resolution: up to 1920x1080p 60 FPS
• Supports WINDOWS/ LINUX/MAC OS
• Support RTSP/ RTP/ RTMP/ RTMPS/ FLV/ HTTP/ ONVIF/ HLS/ SRT / UDP unicast and multicast protocol
• Support Main TS stream and the sub TS stream use in different network protocols for transmission
• Encoding level: 1, 2, 3, 4 and 5(the higher the level, the larger of the code flow fluctuation ratio )
• Coding Standard: Base line profile/ main profile/high profile, H.265 main profile:
• Audio: MP3, AAC, G.711, sampling rate: 32000,44100,48000 etc, encoded audio bit rate: 48K, 64K, 96K, 128K, 160K, 192K, 256K
• Video bitrate Control: CBR / VBR 16KBIT / S 12MBIT / S
• Video packaging: A mode: FFMPEG, B mode: VLC

10.Transmission: TCP, UDP, 100M/ 1000M (RJ45 Duplex network port)

11.Support WEB access in Chinese/ English, passwords change, WAN remote management (WEB)

12.Support Text/ image OSD, images superimposing.

13.Adjustable coordinates: 1920x1080; the font size: 8 to 72.

14.Supports automatically obtain IP (DHCP), support One-key recovery, upgrade and remote maintenance.

15.Image settings: contrast ratio, brightness, tones, saturation, noise detection, sharpness, filtering

16.Support build-in or external audio input, support left and right sound channel, Support audio gain, turn volume individually.

17.Support encoding without video signal;

18.Take effect immediately when applied the settings, dont need to restart.

19.Support one-key recovery to default setting.

20.Low power consumption design.

1U 1channel SDI to IP Encoder
